Barcode Label Printing and Type Options

Barcode Label Printing and Type Options


Barcode Label Types - Printing and Type Options


Bar-coding your assets can really help to transform your asset tracking and audit process. It enables you to quickly access information about an asset and can significantly improve the accuracy of your fixed asset register.

Sourcing the best bar-codes required for your organisation and offers a number of different options depending on the environment in which your assets will be tracked.


For more information on Bar-code Printing Options and Services AssetManager Pro provides refer to our AssetManager Pro OnlineAudit Info Page.


Self or Outsourced Printing


AssetManager Pro and GRAGA Software Solutions provides both the ability to self print Asset Labels (we support the Zebra GK420d printer) and also an outsourced service where we print the labels FOR YOU.

Outsourced Printing
  • Ideal where you need more sophisticated options (Durable and High Security)
  • Also best for “High Volumes”
  • Reduces cost(and complexity) of barcode printer needs
  • Have a professional deal with high volumes than risk huge wastage DIY.
  • Always suggest to use for INITIAL print (if in thousands) then option to use Self-Printing for addition assets.

Self-Printing
  • Best for Low Volumes (Asset Additions)
  • Can be done on-site
  • No lead time
  • Requires
    • AssetManager Pro OnlineAudit module - click here for more details)
    • Investment in printer (we support the Zebra GK420d printer) and can be purchased through GRAGA Software Software Solutions)

For more information on printing and label options email service@assetmanagerpro.com.au or call on +61 3 9016 9454

1D or 2D (QR Code) Labels




Whether you are:

1. Self printing Barcodes through AssetManager Pro (using the Zebra GK420d printer)
2. Getting your labels printed by GRAGA Software Solutions or a 3rd Party

you can either print 1D or 2D (QR Label Codes)

We recommend 2D (QR Code) Labels as they are the easiest and quickest to scan using the AssetManager Pro Mobile Scan iOS App

Supported Label Sizes

AssetManager Pro currently supports the following Label Sizes for Self Printing (or if you are getting labels printing by GRAGA Software Solutions)

Additional Label Sizes available on request. Email service@assetmanagerpro.com.au for more information.


Design

Size

Type


40mm * 28mm

(Core Size 12.7mm to 38.1mm in diameter)

2D Barcode (QR Code)

Direct Thermal or Thermal Transfer

50mm * 25mm


(Core Size 12.7mm to 38.1mm in diameter)

2D Barcode (QR Code)

Direct Thermal or Thermal Transfer



69mm * 48mm


(Core Size 12.7mm to 38.1mm in diameter)

2D Barcode (QR Code)

Direct Thermal or Thermal Transfer


40mm * 20mm


(Core Size 12.7mm to 38.1mm in diameter)

2D Barcode (QR Code)

Direct Thermal or Thermal Transfer



Label Types



Vinyl Barcode Labels

A simple and economic option for simple asset security.

  • Suitable for chemical and abrasion free environments

Polypropylene Barcode Labels



The strength of this label is that it can stick to many types of surface. It can be laminated for extra durability.

  • Suitable for use in temperatures between -10°C to +80°C
  • For both indoor and outdoor use

3M Polyester Barcode Labels



A tough label designed to resist excessive wear and tear, along with all types of chemicals.

  • Suitable for use in temperatures between -40°C to +140°C
  • Sticks to surfaces with its strong 3M acrylic adhesive

Aluminium Barcode Labels & Tags



A very tough metal barcode tag that will survive the most extreme conditions. The tags can have printed colours, text and numbers.

  • For indoor and outdoor use
  • Can survive high temperatures, sunlight, strong wear & tear, chemicals, etc
  • Durable and tough

Tamper Evident/VOID Polyester Barcode Labels



This label indicates if it has been tampered with. It cannot be transferred after application, therefore providing extra security.

  • A ‘VOID’ pattern is displayed if the sticker is removed
  • Laminated for extra durability

Indestructible Barcodes Labels

The indestructible bar-code label is made from specialist material that cannot be removed without causing damage.

  • Ideal for extra security
